Recess Type Pozi Thread L (mm) 55 L (mm) 60 Pack Qty 200 Lubrication Gleitmo Substrates Hardwood, Softwood, Chipboard, MDF, Plastic, Thin Sheet Metal Driver Bit Size PZ2 Corrosion Rating (1-5) 2 – Occasionally damp/wet, rural and sheltered areas Inner Thread Ø d1 (mm) 3.1 Thread Type Single Coarse 40° Point Type 25° Sharp with Single Slash Thread Ø (mm) 5 Finish Zinc & Yellow MOQ Increment 1 MOQ 1 Pack Type Box Packs per Carton 16 Material Carbon Steel Size (mm) 5.0 x 60 Head Type Double Countersunk Feature 5 Single slash on 25mm to reduce torque and the likelihood of the timber splitting when the screw is inserted close to the edge Feature 4 Surface hardened up to 750 HV to prevent torque shearing under load and a core hardness of up to 450 HV for improved ductility Feature 3 40° deep single thread to provide a secure fixing with high pull-out resistance Feature 2 Patented lubrication, designed to enhance screw insertion time and provides greater resistance to corrosion Feature 1 Double countersunk reduces the likelihood of head shear and assists completion of countersinking Feature 6 All sizes up to and including 75mm are fully threaded and lengths 80mm and above all have 70mm thread length Brand TIMCO Thread Coverage Fully Threaded
