Specifically designed as a multi-purpose product, the 25° sharp point, special thread design, lubrication and corrosion resistant plating ensures the screw will consistently perform efficiently in hardwood, chipboard, MDF, plastic and thin sheet metal, whilst offering exceptional holding power. • Double countersunk reduces the likelihood of head shear and assists completion of countersinking • Patented lubrication, designed to enhance screw insertion time and provides greater resistance to corrosion • 40° deep single thread to provide a secure fixing with high pull-out resistance • Surface hardened up to 750 HV to prevent torque shearing under load and a core hardness of up to 450 HV for improved ductility • Single slash on 25mm to reduce torque and the likelihood of the timber splitting when the screw is inserted close to the edge • All sizes up to and including 75mm are fully threaded and lengths 80mm and above all have 70mm thread length Packs per Carton 16 MOQ 1 Point Type 25° Sharp with Single Slash Substrates Hardwood, Softwood, Chipboard, MDF, Plastic, Thin Sheet Metal Thread L (mm) 65 Inner Thread Ø d1 (mm) 3.1 Material Carbon Steel Head Type Double Countersunk Pack Qty 200 Thread Type Single Coarse 40° Size (mm) 5.0 x 70 Pack Type Box Driver Bit Size PZ2 Recess Type Pozi Corrosion Rating (1-5) 2 – Occasionally damp/wet, rural and sheltered areas MOQ Increment 1 Finish Zinc & Yellow L (mm) 70 Lubrication Gleitmo Thread Ø (mm) 5 Feature 1 Double countersunk reduces the likelihood of head shear and assists completion of countersinking Feature 4 Surface hardened up to 750 HV to prevent torque shearing under load and a core hardness of up to 450 HV for improved ductility Feature 5 Single slash on 25mm to reduce torque and the likelihood of the timber splitting when the screw is inserted close to the edge Feature 2 Patented lubrication, designed to enhance screw insertion time and provides greater resistance to corrosion Feature 3 40° deep single thread to provide a secure fixing with high pull-out resistance Brand TIMCO Feature 6 All sizes up to and including 75mm are fully threaded and lengths 80mm and above all have 70mm thread length Thread Coverage Fully Threaded
